The Difference between HDMI Switch and HDMI Matrix Switcher

Opinions on the definition of HDMI matrix switcher and HDMI switch are different, and there is no unified and highly recognizable standard and specification, so it is easy to be confused between the two, and it is uncertain when choosing. Next, let's see if there is only a word difference between them.


1. The function difference between HDMI switch and HDMI matrix switcher


HDMI matrix switcher's main function is to achieve one-to-one or one-to-many arbitrary switching between multiple input sources and multiple displays, with the dual functions of signal switching and signal distribution, which is a multi-input and multiple-output device and can simultaneously display the screen of multiple signal sources. The HDMI switch is generally multi-input and 1-out, such as 2-input and 1-out, 4-input and 1-out, and 8-input and 1-out. Its main function is to switch, repeat, process and copy the image signal transmitted by the system, and it can automatically or manually control multiple video signals, enabling one monitor to display multiple host signals cyclically, and it is impossible to connect multiple monitors, so only one signal source is displayed at a time.


2. The performance difference between HDMI switch and HDMI matrix switcher


HDMI matrix switcher: to achieve automatic gain technology, with power-off field protection function; built-in patrol function, you can set patrol switch, patrol time, and patrol channel; provide up to 32 user-defined output channel configuration schemes, and can adjust the program to store and recall; the matrix can be controlled through the IP address of the matrix control server; it supports panel control, remote control, serial port control, and commonly used network port TCP/IP WEB control.


HDMI switch: output with distribution, signal switching at the same time; fixed 0dB gain; buffered output; support automatic loop switching; optional to participate in automatic loop channel; optional loop switching time; support RS232 remote control.


3. The cost difference between HDMI switch and HDMI matrix switcher


The difference between HDMI matrix switcher and HDMI switch is not only reflected in the function and performance, their cost is also different. Switches from 2-input and 1-out to 64-input and 1-out, the cost may only be tens to thousands of yuan. The minimum specification of HDMI matrix switcher is 2-input and 2-out. The large one can have 72 channels or even hundreds of channels. The cost of such a large matrix can easily cost tens of thousands of yuan, both research and development costs and production costs are much higher than HDMI switches.


Therefore, although the difference between HDMI switch and HDMI matrix switcher is only one word, they provide a very different experience. When selecting the corresponding device according to the needs of use, it does not waste resources and can satisfy its use well.
